320W LED Studio Panel Light
MAIN FEATURES
Rated Voltage: AC100-240V/50-60Hz
Total Power: 320W
Light Source Power: 300W
Light Source: 1200pcs OSRAM P5 (2026) OSRAM 0.5WLED, 240pcs Red, 240pcs Green, 240pcs Blue, 480pcs Warm White
Color Temperature: Adjustable from 2700K to 10000K, CRI≥93, TLCI≥93
Colors: Red, Green, Blue, Warm White, capable of mixing various colors
Control Signal: DMX
Control Modes: DMX signal control or manual button control
Channel Modes: 2-channel, 5-channel, 7-channel, three channel modes available
Dimming: 16-bit or above, flicker-free, smooth linear dimming from 0 to 100%
Inner Dimensions: 590×356×160mm
Package Dimensions: 645x405x220mm
Net Weight: 12.3kg Gross Weight: 14kg
Product Description
The light source consists of 1200pcs of 0.5W OSRAM P5 (2026) LEDs. It includes 240pcs of red, 240pcs of green, 240pcs of blue, and 480pcs of warm white LEDs, collectively generating a powerful and versatile lighting output.
With a lifespan of 100,000 hours, this panel light provides long-lasting and reliable operation while minimizing maintenance requirements. The color temperature is adjustable from 2700K to 10000K, providing a comprehensive range of lighting options. It also boasts a superior Color Rendering Index (CRI) of above 93 and Television Lighting Consistency Index (TLCI) of above 93, ensuring accurate and true-to-life color rendition.
Featuring red, green, blue, and warm white as the primary colors, this panel light allows for precise color mixing, enabling you to create a vast array of captivating lighting effects. With DMX control signal and multiple channel modes (2-channel, 5-channel, 7-channel) available, you have versatile control options to perfectly tailor the lighting to your specific needs.
Enjoy the vibrant and fluid lighting transitions provided by the smooth 0-100% linear dimming. The flicker-free operation guarantees optimal visual performance. With an operating environment humidity ranging from -25°C to 40°C, this panel light is suitable for various ambient conditions.
The inner dimensions of 590×356×160mm ensure a spacious grid for effective heat dissipation and optimized lighting output. The package dimensions are 645*405*220mm, providing secure packaging for transportation and storage.
The panel light has a net weight of 12.3kg and a gross weight of 14kg. This solid yet lightweight construction allows for easy handling and installation in any studio or stage setup.
Unleash your creativity with our 320W LED Studio Panel Light, redefining the possibilities in professional lighting for film, television, events, and more. Create captivating and dynamic visual experiences with ease.
